ATC SEMITEC 104GT-2 104NT-4-16C054RT Thermistor

(1 customer review)

$12.50$13.90

ATC SEMITEC 104GT-2 104NT-4-16C054RT (made in Japan) 300°C

ATC SEMITEC 104GT-2 104NT-4-16C054RT (made in Japan)

Maximum temperature : 300 degree C
Beta value : 4267 K
Resistance at 25 degree C : 100 Kohms

(a) Blue 1m cable 3x15mm copper cartridge: The thermistor insulation is a high temperature kapton sleeve potted into a cylindrical copper cartridge with a high conductivity ceramic based adhesive.
Cable length:1 meter
Cable plug: XH2.54

(b) Thermistor encapsulated in a 3x15mm steel cartridge: The thermistor is insulated with a fibreglass sleeve at the probe and terminated with a connector. The thermistor cable is about 56mm long and can be extended with a 1 or 1.5 metre extension cable. This allows you to disconnect your entire hotend easily without the need for re-wiring.

(c) M4 Stud Screw-In Thermistor: The thermistor is glued into the housing with a high temperature heat conducting glue. Hex brass body with M4 threaded stud allows you to easily screw the thermistor into a M4 hole and avoids falling out halfway through a print. It works for V6 hotends and other types of hotends with a M4 threaded hole in the heater block.
The thermistor cable is about 56mm long and can be extended with a 1 or 1.5 metre extension cable. This allows you to disconnect your entire hotend easily without the need for re-wiring.

(d) M3 Stud Screw-In Thermistor: The thermistor is glued into the housing with a high temperature heat conducting glue. Hex brass body with M3 threaded stud allows you to easily screw the thermistor into a M3 hole and avoids falling out halfway through a print. It works for MK8 hotends and other types of hotends with a M3 threaded hole in the heater block.
The thermistor cable is about 56mm long and can be extended with a 1 or 1.5 metre extension cable. This allows you to disconnect your entire hotend easily without the need for re-wiring.

WeightN/A
Dimensions10 × 5 × 1 cm
Brand

Option

A 1m) 3*15mm – 1m blue with XH2.54, B 1.5m) 3*15mm – extension with XH2.54, B 1m) 3*15mm – extension with XH2.54, C 1m) M4 stud *3mm – extension with XH2.54, C 1.5m) M4 stud *3mm – extension with XH2.54, D 1m) M3 stud *3mm – extension with XH2.54, D 1.5m) M3 stud *3mm – extension with XH2.54

1 review for ATC SEMITEC 104GT-2 104NT-4-16C054RT Thermistor

  1. S**** K****
    April 5, 2024
    Perfect for my Voron 2.4
    Installed and fixed my false temp readings straight away. I didn't need to change my printer cfg, so the product is as described.
